Applications

General Lighting Phosphor Materials

Whether it is indoor, outdoor, retail, hospitality or industrial lighting, Intematix phosphor materials can meet your needs. Being the only company to offer four types of phosphor materials – GAL (Aluminates), NYAG (Garnets), Silicate and Nitride available in any spectral shape, size or particle distribution you wish, makes your wishes reality. If you need a very high R9 rendering, that is possible. If you need 98CRI, that is possible. If you just need an extremely efficient light, that is possible as well.

General Lighting Applications

Nitride - high efficiency, thermal stability and reliability

  • Enables high CRI, up to 98 with widest spectral range to 670nm
  • Enables wide color gamut displays
  • Increases efficacy, thermal stability and lowers costs for high power/flux LED systems

GAL (Aluminate) - wide spectral width, high efficiency, reliability and superior thermal stability

  • Green GAL enables high CRI, up to 98, with the widest spectral width of FWHM (120nm) & increases efficacy, thermal stability and lowers costs for high power/flux LED systems
  • Yellow GAL allows a single phosphor solution for white LEDs and enables LED makers who do not possess IP license to use YAG

NYAG - high efficiency, thermal stability, reliability and consistency

  • Yellow offers the brightest, highest lumens/watt LEDs and lower cost, higher yield LED production, reducing phosphor contributions to binning with reliably consistent color. It is also a straightforward design as single phosphor solution for white LEDs
  • GNYAG – Green YAG offers high efficiency, thermal stability and reliability with high brightness, and a high lumens/watt solution for mid range 80CRI in combination with shorter wavelength red. It also solves problems of sub-optimal CRI and efficacy with YAG yellow and long wavelength red

Silicate - choice of colors blue-green, green, yellow and orange with very high efficiency and narrow spectral width

  • Broad product choice to mix and match to target performance, 507 – 610nm
  • High brightness and lumens per watt
  • Narrow emission peak of 70-82nm, more light passes through display color filter

General Lighting Applications

Solutions

Indoor lighting solution:

  1. GAL with red nitride (patent protected)
  2. GNYAG with red nitride
  3. NYAG with red nitride

Outdoor lighting:

  1. NYAG

Consumer orientation (retail & hospitality):

  1. GAL and red nitride (patent protected)

Learn more about our Phosphor Materials.
